Detecting Principle |
Semiconductor |
---|---|
Measurement Range |
0 to 999 PPPM |
Resolution |
1 PPM |
Operating Temperature |
0 to 55 C |
Operating Humidity |
<95% |
Display Mode |
Seven Segment |
Alarmin Method |
Automatic |
Power Supply |
230V AC/12V AC/24V DC |
Weight |
4 Kg |
Current |
<200mA (in measuring condition) <75mA ( in non measuring condition) in 12V DC |
Optional Function |
Relay output for Gas shut off valve, exhaust fan, input to central security system. |
Gas Option |
LPG, PNG, LNG, CNG, CO, CH4, NH3(C), NH3, H2 |
Power |
12v DC, 24v DC |
